25mm Pot Magnet N35 Black

25mm Pot Magnet N35 Black

Regular price R 41.50 ZAR
Regular price Sale price R 41.50 ZAR
Sale Sold out
Tax included. Shipping calculated at checkout.

 25mm Pot Magnet N35 Black


 Pot magnets with countersunk holes are powerful mounting magnets. These magnetic assemblies are built with N35 neodymium disc magnets embedded in a steel pot. The steel casing creates a strong vertical magnetic pull force (especially on a flat iron or steel surface), concentrating the magnetic force and directing it to the contact surface.

Neodymium pot magnets are high in magnetic strength for their small size, making them ideal for all types of applications where high-strength magnets are required. They are often used for heavy-duty holding, mounting, and fixing purposes in workstations, classrooms, offices, and warehouses, for pop displays, as retrieval magnets, and more.

PRODUCT SPECIFICATIONS:

Material: Neodymium Magnets (NdFeB)
Dimensions: 25mm x 6mm hole/11mm countersunk hole x 8mm thick.
Shape: Round / Circle
QTY: 01 Pcs
Coating: Ni-Cu-Ni (Nickel) + Mild Steel Casing Black
Grading: N35
Tolerance: +/- 0.1
Maximum temperature: N35 grading magnets can work in an environment that has a maximum operating temperature no greater than 80°C.
Pulling Force: 22 KG
Colour: Black
Direction of Magnetism: Through the thickness.

Image: Direction of magnetism


 Pot



Pros and cons:

Pros:
-Plated with a triple layer of Ni-Cu-Ni (Nickel+Copper+Nickel) based process for maximum protection against corrosion & oxidation.

-Best power-to-weight ratio of all magnets.
-High resistance to demagnetization.

-The mild steel casing protects the magnet from damage.

Cons:
-Magnetism starts to decrease (and can be permanently lost) at 80°C. (This depends on the handling of magnets.)
-Low corrosion resistance. (If the plating is damaged)
-Will rust when exposed to wet elements.
-Brittle (May break, crack, or chip upon sudden collisions with other magnets or metals.)
-Drilling magnets causes the magnet to shatter. (Do not drill magnets, as friction can cause fire/explosion due to flammable material.)
-Often higher cost choice

Applications of Pot Magnets:

Fishing for lost objects
Hanging items
Mounting article, used in point-of-sale displays, false ceilings, light fixtures and fittings and general holding applications
Hobby and leisure

________________________________________

Looking for custom sizing, coating, grading or bulk orders: Please contact us at 0218513913 or info@magnetstore.co.za

Please note that only small quantities of the stock are loaded on the website, for higher quantities please contact us.
